Zirconium Oxide Powder
$0.00
Zirconium Oxide Powder
| Product | Zirconium Oxide Powder |
| CAS No. | 1314-23-4 |
| Appearance | White Powder |
| Purity  | ≥99%, ≥99.9%, ≥95%
(Other purities are also available) |
| APS   | 1-5 µM, 10-53 µM (Can be customized), Ask for other available size range. |
| Ingredient | ZrO2 |
| Density | 5.68g/cm3 |
| Molecular Weight | N/A |
| Product Codes | NCZ-MNO-127/25 |
Zirconium Oxide Description:
Zirconium Oxide Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing
Zirconium Oxide Powder Related Information :
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
Zirconium Oxide Powder, Zirconia (ZrO2)
| Catalog No. | NCZ-MNO-127/25 |
| Catalog Number: | 1314-23-4 |
| Chemical Formula | ZrO2 |
| Color | White |
| Melting Point | 2,715° C (4,919° F) |
| Density | 5.68 g/cm3 |
| Purity | 99.9% |
| MSDS/SDS | Download MSDS/SDS |
Zirconium oxide powder has the properties of high melting point, high resistivity, high refractive index, and low thermal expansion coefficient. As a global supplier of Zirconium Oxide (Zirconia), It provides customers with high-quality ZrO2 products in a variety of forms, including tubes, rods, wires, etc.
Zirconium Oxide Powder Description
Zirconium dioxide, commonly known as zirconia, is a highly versatile oxide of zirconium with the chemical formula ZrO2. At room temperature, zirconium oxide is a white, odorless, and tasteless crystal. It is insoluble in water, hydrochloric acid, and dilute sulfuric acid, making it highly durable and chemically stable under a range of conditions.
Zirconium oxide powder is characterized by its high melting point, high resistivity, and low thermal expansion coefficient, which make it an indispensable material in various high-performance applications. It is commonly used as a high-temperature resistant material, ceramic insulator, and ceramic sunscreen. In addition to these industrial uses, zirconia is also a key raw material for producing artificial diamonds, thanks to its excellent hardness and optical properties.
This high-purity 99.9% zirconium oxide powder is ideal for applications that require extreme durability, thermal resistance, and electrical insulation. The powder is available in a range of particle sizes to suit different manufacturing processes and is widely used in the production of advanced ceramics, electronics, and aerospace materials.
Zirconium Oxide Powder Specifications
| Chemical Composition (%) | ||||||||||||||
| No. | OZ-P | OZ-B-1 | OZ-B-2 | OZ-R-1 | OZ-R-2 | OZ-R-3 | OZ-R-4 | OZ-R-5 | OZ-R-6 | OZ-R-7 | OZ-R-J | |||
| Zr(Hf)O2 | 99.9 | 99.9 | 99.9 | 99.9 | 99.5 | 99.5 | 99.5 | 99.5 | 99.5 | 99.5 | 99.5 | |||
| SiO2 | 0.02 | 0.007 | 0.01 | 0.01 | 0.015 | 0.015 | 0.015 | 0.015 | 0.002 | 0.002 | 0.05 | |||
| Fe2O3 | 0.003 | 0.0005 | 0.0006 | 0.0006 | 0.002 | 0.002 | 0.002 | 0.002 | 0.005 | 0.005 | 0.01 | |||
| TiO2 | 0.003 | 0.001 | 0.0015 | 0.0015 | 0.003 | 0.003 | 0.003 | 0.003 | 0.005 | 0.005 | 0.005 | |||
| Na2O | 0.005 | 0.001 | 0.0015 | 0.0015 | 0.003 | 0.003 | 0.003 | 0.003 | 0.005 | 0.005 | 0.01 | |||
| CaO | 0.005 | 0.001 | 0.0015 | 0.0015 | 0.003 | 0.003 | 0.003 | 0.003 | 0.005 | 0.0
05 |
0.01 | |||
| Physical Properties | ||||||||||||||
| Particle Size (Mesh) | – | – | 60-150 | – | – | – | – | 60-325 | – | – | – | |||
| Specific Surface Area (m2/g) | <10 | 1-4 | 1-4 | 1-4 | 2-6 | 2-6 | 2-6 | 2-6 | 3-7 | 3-7 | 2-6 | |||
| D50 (μm) | <1.0 | – | – | 3-6 | 3-6 | 6-8 | – | – | 1<D50<3 | ≤1.0 | 306 | |||
Zirconium Oxide Powder Applications
Zirconium oxide powder is used in a wide range of applications due to its excellent properties such as high melting point, chemical stability, and durability. Some of the key applications include:
Raw Material for Metal Zirconium and Its Compounds: Zirconium oxide is a critical component in the production of metal zirconium and other zirconium-based compounds, which are used in various industrial processes.
Refractory Materials: Due to its high melting point, zirconium oxide is used extensively as a refractory material in high-temperature applications such as furnaces and kilns.
Thermal Barrier Coatings: The application of plasma-sprayed zirconium dioxide thermal barrier coatings on aerospace and industrial gas turbines has seen significant progress. These coatings help protect components from extreme temperatures and wear.
Ceramic Materials: Zirconium oxide is used in the production of advanced ceramics, which find applications in cutting tools, dental ceramics, and other high-performance ceramic products.
Incandescent Gas Lampshades and Enamels: Zirconium oxide is used in the manufacture of incandescent gas lampshades, enamels, and white glass, where its high stability and durability are essential.
Refractory Crucibles: It is also utilized in the creation of refractory crucibles, which are used to melt and handle metals at high temperatures.
Zirconium Oxide Powder Packaging
Zirconium oxide powder is carefully handled to prevent damage during storage and transportation and to preserve the quality of our products in their original condition.
Description
Description
Note: For pricing & ordering information, please get in touch with us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at (+1 780 612 4177) if you have any questions.
