Barium Titanate Powder
$0.00
Barium Titanate Powder
| Product | Barium Titanate Powder |
| CAS No. | 12047-27-7 |
| Appearance | White Powder |
| Purity | ≥99%,  ≥99.9%,  ≥95%(Other purities are also available) |
| APS/Particle Size | 1-5 µM, 10-53 µM  (Can be customized),  Ask for other available size range. |
| Ingredient/Formula | BaTiO3 & BaTi4O3 |
| Density | 6.02 g/cm3 |
| Molecular Mass/Weight | 233.192 g |
| Product Code | NCZ-DCY-102/25 |
Barium Titanate Powder Description:
Barium Titanate Powder is one of the numerous advanced ceramic materials manufactured by Nanochemazone. Nanochemazone produces too many standard grades when applicable, including Mil Spec (military grade); ACS, Reagent and Technical Grade; Food, Agricultural and Pharmaceutical Grade; Optical Grade, USP and EP/BP (European Pharmacopoeia/British Pharmacopoeia) and follows applicable ASTM testing standards. Typical and custom packaging is available. Additional technical, research and safety (MSDS) information are available. Please request a quote above for more information on lead time and pricing.
Barium Titanate Powder Related Information:
Storage Conditions:
Airtight sealed, avoid light and keep dry at room temperature.
Please contact us for customization and price inquiry
Email: contact@nanochemazone.com
Note: We supply different size ranges of Nano and micron as per the client’s requirements and also accept customization in various parameters.
Barium titanate is the inorganic compound with the chemical formula BaTiO3. Barium titanium oxide is a white powder and transparent as larger crystals. This titanate is a ferroelectric ceramic material, with a photorefractive effect and piezoelectric properties.
Other Names: Barium Titanium Oxide
Chemical formula: BaTiO3 & BaTi4O3
CAS No.: 12047-27-7
Appearance: White Powder
Molar mass: 233.192 g
Melting point: 1,625°C (2,957˚F; 1,898K)
Density: 6.02 g/cm3, solid
Barium Titanium oxide is slightly soluble in dilute mineral acids; Dissolves in concentrated hydrofluoric acid; Insoluble in water.
Physical Properties
| Item | Data | Method |
| Particle size D50 (μm) | 0.5-2.0 | Laser Measurement |
| Moisture (wt%) | <0.3 | At 105°C (1 Hour) |
| Ignition loss (wt%) | <0.5 | At 800°C (1 Hour) |
| Crystal Form (BaTiO3) | Tetragonal | XRD |
| Type | BT-1 | BT-2 | BT-3 |
| Purity (wt%) | ≥99.5 | ≥99 | ≥99 |
| SrO (wt%) | <0.05 | <0.10 | <0.30 |
| Fe2O3 (wt%) | <0.01 | <0.03 | <0.10 |
| K2O+Na2O (wt%) | <0.01 | <0.03 | <0.15 |
| Al2O3 (wt%) | <0.10 | <0.20 | <0.15 |
| SiO2 (wt%) | <0.10 | <0.20 | <0.30 |
Applications:
As a basic inorganic dielectric material, Barium titanate is widely used in the area of ceramic capacitor, PTC Thermistor, Wave Filter, Chemical Catalyst, Organic Compound and their performance improvement with excellent dielectric, temperature and chemical properties. .
Barium titanate is also a piezoelectric material for microphones and other transducers
Description
Description
Note: For pricing & ordering information, please get in touch with us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities and customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) is available upon request.
NOTE:
Images, pictures, colors, particle sizes, purity, packing, descriptions, and specifications for the real and actual goods may differ. These are only used on the website for the purposes of reference, advertising, and portrayal. Please contact us via email at sales@nanochemazone.com or by phone at (+1 780 612 4177) if you have anyÂ
