CVD Graphene on Quartz Substrate
$0.00
| Product Name |
CVD Graphene on Quartz Substrate |
| Stock No. | NCZ-GSW-0020 |
| Purity | > 99.9% |
| Graphene Film | |
| FET Electron Mobility on Al2O3 | 2000 cm2/Vs |
| Hall Electron Mobility on SiO2/Si | 4000 cm2/Vs |
PRODUCT DETAIL
CAS No.: 7782-42-5 (graphene)
| Sheet Resistance | <600Ω/sq |
| Custom Order | <300Ω/sq |
| Transparency | >95% |
| CVD Graphene | Substrate |
| 1cm x 1cm | Diameter: 1inch, Thickness: 3mm* |
| 1inch x 1inch | 30mm x 30mm, Thickness: 1mm |
We can also provide 15mm x 15mm and 1mm thick substrate and other sizes based on your request. Please contact us for more information.
Description
Note: For pricing & ordering information, please contact us at sales@nanochemazone.com
Please contact us for quotes on Larger Quantities & Customization. E-mail: contact@nanochemazone.com
Customization:
If you are planning to order large quantities for your industrial and academic needs, please note that customization of parameters (such as size, length, purity, functionalities, etc.) are available upon request.
Shipping & Delivery
